BLT Item #: | BKY3331 |
Mfg. Part #: | 32203 |
Mfg.: | Verbatim |
Description: | 140W GAN WALL CHARGER 4-PORT GAN CHARGER (ORDERED AS NEEDED FROM MFG) |
Weight: | 0.86 lbs. |
Dimensions: | 4.3” x 1.9” x 5.2” |
UPC: | 023942322030 |
Brand and Item Information | |
Brand: | Verbatim |
Name: | Verbatim GNC-140 Universal Black, Gray AC Fast charging Indoor |
Brief Description: | Verbatim GNC-140, Indoor, AC, 20 V, Black, Gray |
Warranty: | 2 year warranty |
Technical Details | |
Sustainability certificates: | REACH, RoHS |
Compliance certificates: | REACH, RoHS |
Sustainability compliance: | Yes |
Weight & Dimensions | |
Width: | 1.23” (31.3 mm) |
Depth: | 3.01” (76.5 mm) |
Height: | 2.67” (67.7 mm) |
Weight: | 0.6 lbs (270 g) |
Power | |
Input voltage: | 100 - 240 V |
Input frequency: | 50/60 Hz |
Input current: | 2.1 A |
Maximum power: | 140 W |
Maximum output voltage: | 20 V |
Minimum output voltage: | 3.3 V |
Port 1 output power: | 140 W |
Port 2 output power: | 140 W |
Port 3 output power: | 20 W |
Port 4 output power: | 18 W |
Output current (5V): | 3 A |
Output current (9V): | 3 A |
Output current (12V): | 3 A |
Output current (15V): | 3 A |
Output current (20V): | 5 A |
Port 1 output current: | 5 A |
Port 2 output current: | 5 A |
Port 3 output current: | 3 A |
Port 4 output current: | 3 A |
Compatible power plug types: | EU, UK, US |
Operational Conditions | |
Operating temperature (T-T): | -10 - 40 °C |
Storage temperature (T-T): | -20 - 80 °C |
Operating relative humidity (H-H): | 5 - 90% |
Packaging Data | |
Quantity per pack: | 1 pc(s) |
Package type: | Hanging box |
Package width: | 1.85” (47 mm) |
Package depth: | 4.33” (110 mm) |
Package height: | 5.18” (131.5 mm) |
Package weight: | 0.86 lbs (390 g) |
Packaging Content | |
AC adapter included: | Yes |
Design | |
Product color: | Black, Gray |
Housing material: | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
Plug and Play: | Yes |
Gallium nitride (GaN) transistors: | Yes |
Performance | |
Charger type: | Indoor |
Charger compatibility: | Universal |
Power source type: | AC |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 1 |
USB Type-C ports quantity: | 3 |
Fast charging: | Yes |
Fast charging technology: | Quick Charge 3.0 |
Programmable power supply (PPS): | Yes |
USB Power Delivery: | Yes |
USB Power Delivery up to: | 140 W |
Power protection features: | Over current, Over voltage, Overheating, Short circuit |
Country of origin: | China |
