Need flexibility? Connect to other monitors and devices with HDMI and a display port. While the HDMI supports FHD monitors, the display port can support up to 4k resolution or 3 FHD monitors.
The Trusted Platform Module 2.0 is a commercial-grade security chip installed on the motherboard that creates and stores passwords and encryption keys. It verifies that the computer has not been tampered with before booting up and protects your data against external software attacks. Plus, a Kensington lock slot and padlock loops provide extra physical security for your equipment.
Main Specification
|
Product Features
|
General | |
---|---|
Type | Personal computer |
Bundled Services | 1 Year Dell Collect and Return Service - Disti SNS |
Product Form Factor | Small form factor |
Embedded Security | Trusted Platform Module (TPM) Security Chip |
Colour | Black |
Processor / Chipset | |
---|---|
CPU | Intel Core i5 (12th Gen) 12400 |
Clock Speed | 2.5 GHz |
Max Turbo Speed | 4.4 GHz |
Number of Cores | 6-core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Chipset Type | Intel B660 |
Cache Memory | |
---|---|
Installed Size | 18 MB |
Cache Per Processor | 18 MB |
RAM | |
---|---|
Installed Size | 8 GB / 64 GB (max) |
Technology | DDR4 SDRAM |
Effective Memory Speed | 3200 MHz |
Rated Memory Speed | 3200 MHz |
Form Factor | DIMM 288-pin |
Slots | 2 (Total) / 1 (empty) |
Configuration Features | 1 x 8 GB |
Hard Drive | |
---|---|
Type | SSD - M.2 |
Capacity | 1 x 512 GB |
Interface Type | PCI Express |
Features | NVM Express (NVMe) |
Storage Controller | |
---|---|
Type | 1 x SATA |
Optical Storage | |
---|---|
Type | No optical drive |
Card Reader | |
---|---|
Type | Card reader |
Supported Flash Memory Cards | SD Memory Card, SDHC Memory Card, SDXC Memory Card |
Monitor | |
---|---|
Monitor Type | None. |
Graphics Controller | |
---|---|
Graphics Processor | Intel UHD Graphics 730 Shared Video Memory (UMA) |
Video Interfaces | HDMI, DisplayPort |
Audio Output | |
---|---|
Compliant Standards | High Definition Audio |
Input Device | |
---|---|
Type | Mouse (on selected markets only), keyboard (on selected markets only) |
Keyboard | |
---|---|
Keyboard Name | Dell KB216 Wired Keyboard |
Mouse | |
---|---|
Mouse Name | Dell MS116 USB Optical Mouse |
Technology | Optical |
Interface | USB |
Networking | |
---|---|
Interface (Bus) Type | M.2 2230 |
Ethernet Controller | Realtek RTL8111HSD |
Wireless LAN Supported | Yes |
Wireless NIC | Realtek RTL8821CE |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Features | MU-MIMO Support, single stream (1x1) |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Expansion / Connectivity | |
---|---|
Bays | 1 (total) / 1 (free) x external 5.25" Slim Line |
Slots | 1 (total) / 0 (free) x M.2 Card - 2230/2280 (for SSD) 1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) 1 (total) / 1 (free) x PCIe x16 - half-height 1 (total) / 1 (free) x PCIe x1 - half-height |
Interfaces | 1 x headphones/microphone (1 in front) 4 x USB 3.2 Gen 1 (2 in front) 4 x USB 2.0 (2 in front) 1 x LAN (Gigabit Ethernet) - RJ-45 1 x DisplayPort 1.4 1 x HDMI 1 x audio line-out |
Miscellaneous | |
---|---|
Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
Security Slot Type | Noble Wedge security slot |
Pricing Type | Build To Stock (BTS) |
Power | |
---|---|
Device Type | Power supply |
Voltage Required | AC 90-264 V (50/60 Hz) |
Power Provided | 180 Watt |
80 PLUS Certification | 80 PLUS Bronze |
Efficiency | 85% |
Operating System / Software | |
---|---|
OS Provided | Windows 11 Pro Dutch / English / French / German / Italian |
Software | Microsoft Office (30 days trial, excludes office licence), Windows System Driver, McAfee Business Protection - 30 days trial (UK - 1 year) |
Sustainability Information | |
---|---|
ENERGY STAR Certified | Yes |
Dimensions & Weight | |
---|---|
Width | 9.26 cm |
Depth | 29.28 cm |
Height | 29 cm |
Weight | 4.52 kg |
Environmental Parameters | |
---|---|
Min Operating Temperature | 10 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 20 - 80% (non-condensing) |
