GAMEMAX GM MODULAR 600W POWER SUPPLY

€99.00
Sold out
Product Details

GameMax Semi-Modular Series is a semi-Modular PSU with a compact and quiet engineering, with semi-modular cables for easy maintenance, allowing you to only connect cables that your system needs. Fewer cables allows it to be tidy and better airflow inside your case. High 80 Plus efficiency, reduced ripple and electrical instabilities and better efficiency and protection gives the user durability and total confidence in your next system build. 100% 6th Generation Skylake Ready!

  • PSU Type: ATX
  • Cabling: Semi-Modular
  • Efficiency: 85+ Bronze
AC INPUT: 100-240 VAC 8-4A 50-60Hz
DC
Output
Max
+3.3V +5V +12V1 +12V2 -12V +5VSB
18A 18A 20A 20A 0.5A 2.5A
600W

Connectors

GameMax 20+4 Pin Main Connectors:

1
GameMax 4+4 Pin 12V Connectors:

1
GameMax SATA Connectors:

6
GameMax 4-Pin Molex Connectors:

3
GameMax 6+2 Pin PCI-e Connectors:

2

Detailed Specifications

Dimensions: 160mm x 85mm x 150mm (W x H x D)
Input Voltage: 100-240 VAC
Input Current: 6-10A
Input Frequency Range: 50-60Hz
PFC: Active PFC (>.99)
Power Good Signal: 100-500 ms
Hold Up Time: >17ms
Efficiency: > 81% (85% max)
MTBF: > 100,000 Hours
Protection: OVP / UVP/ OTP / OCP / OLP / OPP / SCP
Power: 600W
Operation Temperature: 0-40C
Safety: CE / FCC / CB
Cooling: 140mm Ultra Silent Fan
Noise: <25dBa
80 Plus Certified: Yes - 80 Plus Bronze

General Specifications

Manufacturer Part Number: GM-600
EAN Number: 6931858730020
Has Mains Plug: No
Colour: Black
What's In The Box: Power Supply
Screws
Manual
5 x Output Cables
2 x Cable Ties
Unit (Product) Dimensions (mm): 160mm x 85mm x 150mm (W x H x D)
Packaging Dimensions (mm): 335mm x 242mm x 122mm (W x H x D)
Net Weight (KGs): 1.8 KGs
Gross Weight (KGs): 2.5 KGs
